CNC Horizontal Drilling Machine


CNC Horizontal Drilling Machine

Single worktable panel length ≤2550mm

Multi-worktable panel length ≤800mm

Panel width ≥60mm

Panel thickness 10-50mm

Maximum speed 75m/min

Processing methods Laser scanning+canning label

Drilling motor 2.2kw(18000rpm)

Worktable Three worktable

Total power 3.35kw

Overall size 3200*2100*1500mm

Drilling depth 50mm

Maximum drilling diameter 12mm


Horizontal Multi Sides Cnc Boring Machine Cnc Wood Drilling Machine for Wood Furniture Cabinet Door Plywood Panels


1CK-260CNC horizontal drill is an economical and practical panel furniture horizontal hole making equipment, it can composed economical plate furniture production line with cutting machine, 2.It can replace the traditional table saw and row drilling. Its biggest advantage is that it can scan the side holes directly, cast off the traditional processing methods depend on the chief Boring. 3.The machine is mainly used to solve the problem that the CNC drilling machine can not drills the side holes.Easy to operate,truly make intelligent production with high precision and speed. 4.CNC horizontal single row drilling machine can drill horizontal holes through automatic induction vertical hole. High drilling speed, high efficiency, realize 0 error processing.

Product Paramenters
Model
 CK-260 Wood Drilling Machine
Spindle
2 Spindle Drilling Holes
Traveling speed
60m/min
Type of transmission
X rack/Z ball screw
Max working size
2800*50mm
Drive system
Special Servo Motor
Operated system
Special Control System
Customized
Logo, working area, power, etc
After-sales Service Provided
Online support, Video technical support, Free spare part
