Loading and unloading ATC CNC Router Machine
X,Y,Z Working Area:1300X2500X200mm
Table Size:1855X3340mm
X,Y,Z,Traveling Positioning Accuracy: ±0.03/300mm
X,Y,Z,Repositioning Positioning Accuracy:±0.05mm
Lathe Bed Strong lathe bed:Gantry Steel structure gantry design
Guide Rail :taiwan Hiwin Square Rail with X,Y,Z axis
XY Z Transmission :Gear rack with X and Y axis Imported Ball Screw with Z axis
Spindle Motor :9kw HQD Air cooling spindle special for tool changer
Max. Speed :0-45000mm/min
Max. Working Speed 0-25000mm/min
Spindle Speed 0-24000RPM
Drive Mode Servo system
Working Voltage AC220V/380V, 50/60Hz
Command G Code, *uoo, *mmg, *plt
Inverter 11KW Fuling inverter
Features:
-With 12pcs linear type automatic tool changer system, meet customer’s different working requirements. 10pcs, 12pcs or more magazines are optional
-With vacuum table and powerful vacuum pump, allows you to hold the work-piece on the surface of the table automatically, increases working efficiency.
-Low noise during spindle operation, fine working environment.
-Equipped with High-quality accessories, allows the machine to work 24 hours a day continuously.
-Easy to learn and operate, we will offer special educational video and other educational materials in English.
-Long warranty period
Technical Parameters:
|
Model |
S10 |
|
|
Working travel |
X axis |
1300mm |
|
Y axis |
2500mm |
|
|
Z axis |
200mm |
|
|
Table structure |
Vacuum suction |
|
|
Orbit |
HIWIN or PMI square orbit |
|
|
Transmission type |
X,Y Rack,Z Ball screw |
|
|
Working accuracy |
±0.05 |
|
|
Repositioning accuracy |
±0.05 |
|
|
Max.Idle speed |
60000mm/min |
|
|
Max.working speed |
25000mm/min |
|
|
Spindle parameters
|
Type of cooling |
Imported Italian HSD air cooling spindle |
|
Power |
9kw |
|
|
Speed |
0-24000r/min |
|
|
Inverter |
11kw Sunfar Inverter |
|
|
Drive system |
Leadshine 1500w servo motor |
|
|
Command code |
G code |
|
|
Control system |
LNC Or Ncstudio controller system |
|
|
Oiling system |
Automatic |
|
|
Working voltage |
AC380V/3PH/50HZ |
|
Applicable Materials:
The Machine is suitable for working with materials such as: all kinds of woods, all kinds of plastics, composite, plywood, MDF, polystyrene, wax, PVC and many other materials. And it can also work with materials such as copper, brass, aluminum, etc.
